Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment

Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment

fire testing machine for building materials

surface burning characteristics testing equipment

flammability testing equipment with warranty

Tempat asal:

Cina

Nama merek:

YUYANG

Sertifikasi:

CE

Nomor model:

YY410

Hubungi Kami
Permintaan Penawaran
Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment
Rincian produk
Bahan penutup atap kayu lapis, ukuran:
1.300 (w) × 1.000 (d) × 120 (h)
Catu daya:
380V 50Hz Sistem Lima Fase Lima Fase
Uji tungku terowongan:
3.Length 7.62m, Buka Bagian Penampang End 0.45m * 0.3m, Suhu Maks Firebrick 2500 ℃
Sudut pembakar:
45 °
Sumber gas:
> 95% gas propana; （Pengguna harus menyediakan untuk diri mereka sendiri）
Tekanan gas:
10kpa~50kpa
Menyoroti:

fire testing machine for building materials

,

surface burning characteristics testing equipment

,

flammability testing equipment with warranty

Syarat Pembayaran & Pengiriman
Kuantitas min Order
Set/set
Harga
pending
Waktu pengiriman
5
Syarat-syarat pembayaran
L/c, t/t
Menyediakan kemampuan
20
Produk terkait
Harga yang bagus Building Materials Ignitability Flammability Tester for Single Flame Source Test on line

Building Materials Ignitability Flammability Tester for Single Flame Source Test

Dapatkan Harga Terbaik
Harga yang bagus Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment on line

Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment

Dapatkan Harga Terbaik
Harga yang bagus YY-121 Building Materials Difficult Flammability Test Equipment on line

YY-121 Building Materials Difficult Flammability Test Equipment

Dapatkan Harga Terbaik
Harga yang bagus Kelas II A2 Kabinet Keamanan Biologi dengan kedalaman 780mm on line Video

Kelas II A2 Kabinet Keamanan Biologi dengan kedalaman 780mm

Dapatkan Harga Terbaik
Hubungi Kami
86-769-26622869
Hubungi Sekarang
Deskripsi Produk
Fire Testing Machine for Building Materials
YY410 UL790 Fire Performance Tester for evaluating surface burning characteristics of building materials and photovoltaic cell modules.
Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment 0 Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment 1 Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment 2 Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment 3 Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment 4
Scope of Application
This equipment evaluates roofing materials exposed to simulated exterior building fires, assessing fire resistance at distances of 1.82m, 2.4m and 3.9m to Class AC. Also suitable for testing photovoltaic cell module fire resistance.
Compliance Standards
  • UL 1730 Smoke Detector Monitors
  • UL 790 Standard Test Method for Fire Testing of Roof Coverings
  • IEC 61730-2 Photovoltaic Modules Appendix A Fire Tests
  • ASTM F 108-04 Standard Test Method for Fire Tests of Roof Coverings
  • NFPA 256 Fire Tests for Roof Coverings
Performance Parameters
  • Plywood roof covering material: 1,300(W) × 1,000(D) × 120(H) mm
  • Non-combustible test plate to block tempering
  • Adjustable fan plate: 1,440(L) x 940(H) mm
  • Corrosion-resistant steel main frame: 1,020(L) x 1,000(D) x 1,473(H) mm
  • Non-combustible panel assembly: 330(W) x 2,130(D) x 584(H) mm
  • Test panel air flow rate: 19±8 km/h (5.5m/sec) with anemometer
  • Independent air duct with honeycomb filter screen
  • Stainless steel air duct: 2,130(W) x 762(H) x 5,200(L) mm
  • 380V, 50HZ three-phase power fan with reverse system (min flow 300m³/min)
  • Gas burner: 1.12m long, diameter 60.3mm with 12.7mm wide slit
  • Gas burner capacity: 22,000Btu/min (387kWh) with automatic flow adjustment
  • Automatic ignition system (minimum 1.8kVp)
  • Data acquisition system with LabView programming and NI modules
  • Industrial control computer with 21-inch monitor and test software
  • Sample ignition device adjustable to 880±10℃
  • Rotatable metal grid for material support
  • Advanced temperature and fan wind speed control systems
  • Comprehensive gas leakage and carbon monoxide safety alarms
  • Power requirements: 380V 50HZ three-phase, ≥30KW
Equipment Description
The system consists of an adjustable test platform, non-combustible panel assembly, gas burner, supply fan with air channel, isolation plate, and fire panels. Tests must be conducted in a controlled environment (10-32°C) with all openings closed to prevent external interference.
Before testing, mortar should fill gaps between roof covering material and frame to prevent air/flame passage. Airflow must be calibrated using 1m×1.3m plywood at specified inclination (127mm/300mm).
Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment 5 Fire Testing Machine, Used for Building Materials, Surface Burning Characteristics Testing Equipment 6
