Name: BS476-6 Building Materials Flammability Testing Equipment 530J/S 1kPa
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YYF015
Price: 5000 USD
Availability: InStock

Rumah > Produk > Peralatan Uji Mudah-menyala >

BS476-6 Building Materials Flammability Testing Equipment 530J/S 1kPa

BS476-6 flammability testing equipment 530J/S

building materials flammability tester 1kPa

flammability testing equipment with warranty

Tempat asal:

Cina

Nama merek:

YUYANG

Sertifikasi:

Nomor model:

YYF015

Hubungi Kami

Permintaan Penawaran

BS476-6 Building Materials Flammability Testing Equipment 530J/S 1kPa

Rincian produk

Nama Produk:

Penguji Indeks Perambatan Api

Pelepasan Panas Lampu:

530J/Dtk

Penggunaan:

Penguji Indeks Perambatan Api

Suhu lingkungan:

Pengoperasian 10°C Hingga 35°C

Listrik:

Nominal 230 Volt 10 AMPS

Tekanan:

1KPa

Mengalir:

sebagai aliran untuk pembakar yang dapat disesuaikan dari 0 hingga 5 nl/mnt

Ukuran:

Peralatan: 400mm (L) X 600mm X (T) X 300mm (D)

Berat:

sekitar 50kg

Paket Transportasi:

kasus kayu lapis

Menyoroti:

BS476-6 flammability testing equipment 530J/S

building materials flammability tester 1kPa

flammability testing equipment with warranty

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 buah

Harga

$5000

Kemasan rincian

Kotak Kayu

Waktu pengiriman

7-30 hari

Syarat-syarat pembayaran

T/T

Produk terkait

BS476-6 Building Materials Flammability Testing Equipment 530J/S 1kPa

Dapatkan Harga Terbaik

Video

Alat Uji Kepadatan Asap Pembakaran atau Dekomposisi Material Bangunan

Dapatkan Harga Terbaik

High-Precision Tester: Glass/Metal/Plastic 3/4-Point Bending, Tensile & Compression

Dapatkan Harga Terbaik

EN ISO 11925-2 Peralatan Uji Kemampuan Membakar Bahan Bangunan

Dapatkan Harga Terbaik

Hubungi Kami

8613825729462

sales03@yuyangtest.com

86-769-26622869

Hubungi Sekarang

Deskripsi Produk

BS476-6 Building Materials Flammability Testing Equipment 530J/S 1kPa

BS476-6 Fire Propagation Index Tester for Building Materials and Structures

BS 476 part 6 specifies a method of test where the result is expressed as a fire propagation index, providing a comparative measure of the contribution to the growth of fire made by an essentially flat material, composite or assembly. This equipment is primarily intended for the assessment of the performance of internal wall and ceiling linings.

During testing, the specimen is exposed to a tubular torch with a heat release of 530J/S. After 2 minutes and 45 seconds, two electric heaters are adjusted to 1800 watts total. Five minutes after test initiation, power is reduced to 1500 watts and maintained until test completion, with a total test duration of 20 minutes.

The apparatus assesses flame propagation properties by continuously recording chimney temperature and room temperature difference using thermocouples. Results are compared with calibration curves based on asbestos-cement slab density measurements. Temperature differences are recorded at 30-second intervals for the first 3 minutes, 1-minute intervals for minutes 4-10, and 2-minute intervals for minutes 11-20. Flame spread indices for these three periods are calculated according to standard formulas.

The final index (I) represents the sum of the three period flame spread indices. Higher I values indicate lower material flame retardancy, with grade 0 materials having I ≤ 12.

Standards Compliance

BS 476 Part 6 A1: 2009

GB/T 17658-1999

Key Features

Stainless steel support frame and Calcium silicate board combustion chamber
Three sample holders for different specimen thicknesses
Low reflective black finished mild steel Chimney and Cowl assembly with thermocouple mounting points
Compliant stainless steel gas burner
Two K type mineral insulated thermocouples with ceramic insulators
Two pencil type heaters with 1000w installed in combustion chamber
Control gas instrumentation including electronic gas on/off valve, flow regulating valve, flow meter and manometer
Intelligent single phase power controller with feedback loop for accurate control of electric heating elements
DAQ automatically records mV output from thermocouples throughout test duration
Automatically adjusts output power according to test time

PC Controlled Fire Propagation Apparatus - Walls And Ceilings Flame Spread Test

Specification	Details
Electrical	230 volts Nominal 10 Amps
Ambient Temperature	Operating 10°C to 35°C
Gas Supplies	Standard test gas G112, as specified in BS 4947
Flow	Gas flow for burner adjustable from 0 to 5 nl/min
Pressure	1kPa
